ELECTRICAL DATA
-------------------------------------------------------
Module Type ------------------- SL220-20M
Nominal Peak Power(Wp) ---- 230W
Nominal Voltage(Vmp) -------- 29.9V
Nominal Current(Imp) -------- 7.69A
Open Circuit Voltage(Voc) --- 37.2V
Short Circuit Voltage(Isc) ---- 8.24A
Module Efficiency --------------14.0%
Maximum System Voltage ---1000V DC
MECHANICAL DATA
-------------------------------------------------------
Solar Cell - 60 Poly or Mono-crystalline 156 x 156mm
Front Glass --- 3.2mm tempered
Junction Box -- IP 65 rated
Output cables--900mm length cable MC III or MC IV connectors compatible
Frame ---------- Anodized aluminium
Weight --------- 20kg
Dimension------ 1652 x 1000 x 50mm
TEMPERATURE COEFFICIENTS
-------------------------------------------------------
Nominal Operating Cell Temp.(NOCT) --- 45+/-2 C
Voltage Temp. Coefficient(Voc) ---------- -0.36%/C
Current Temp. Coefficient(Isc) ----------- +0.033%/C
Power Temp. Coefficient(Pmpp) --------- -0.44%/C
Minimum Power Tolerance ---------------- +/-3%
